Working voltage : 24V Max power : 24W
Beam angle: 360 Deg IP Grade : IP65
LED Specification: 5050RGB LED Qty: 144PCS
Pixel: 24PCS Grey scale: 256
Channel : RGB Weight: 0.53KG
1m 360 Degree LED Tube Dimensions:
360 degree beam angle without dark area;
The parts at both ends of the led tube can be detached and installed;
LED tube can be connected in series end by end, the male connector is input and female
connectoris output.
1m 360 Degree LED Tube Dimensions:
360 degree beam angle without dark area;
The parts at both ends of the led tube can be detached and installed;
LED tube can be connected in series end by end, the male connector is input and female
connectoris output.
Signal foldback, can be connected in series with T-cable;
Three installation methods
Hole ball installation
Hole ball connection, the two ends of the 360 degree led tube are inserted into
the hole ball with connecting rods, which can build a variety of three-dimensional shapes
Hanging ring installation
Hang 360 degree led tube with ring.
Floor stand installation
Make led tube stand up on floor with floor stand.
Connection and control way
Connect led tube with controller
Hanging ring installation
Hang 360 degree led tube with ring.
Floor stand installation
Make led tube stand up on floor with floor stand.
Connection and control way
Connect led tube with controller
Connect the XLR cable with controller. Connect the output cable of XLR cable
with input cable of led tube( male connector is input, female connector is output)
Connect led tube with T -cable, and the rotation is locked to prevent accidents
from falling off.
Connect controller with software
Connect controller with computer with Ethernet Cable.
Connect controller with console
Connect controller with console with transfer board.
Connect controller with computer with Ethernet Cable.
Connect controller with console
Connect controller with console with transfer board.
